1. Support multiple communication methods such as BT, Wi-Fi, GPRS/WCDMA, et£»
2. Covering multiple modules such as 1Dl/2D, NFC, RFID, etc., one machine with multiple functions and powerful performance;
3. Support more than 2m distance for EPC C1 GEN2/ISO18000-6C protocol 900MHz label reading operation£»
4. Support 8 million pixel camera auto focus£»
5. Support fingerprint recognition;
6. 11000mAh large-capacity battery, a single charge can provide up to 15 hours of battery life, convenient for long-term outdoor office;
7. Military grade three prevention quality, designed for special industries, completely dustproof, waterproof, shockproof, extreme temperature, harsh environment.
|
Model |
VS-S1008B-P |
|
Performance |
|
|
Processor |
Ten-core 64-bit ARM processor 2.4Ghz Cortex A72 |
|
Operating System |
Andriod 8.1 |
|
Memory Capacity |
6GB RAM+128GB ROM Two-in-one low power memory |
|
Storage |
Micro SD card(T-FLASH card) the card reader supports up to 128GB expansion |
|
Screen |
7.9 inches AFFS/IPS full viewing angle VGA resolution 768x1024 Industrial grade 420cd/m2 high-brightness screen visible in the sun |
|
Wi-Fi£¨Standard£© |
Compliant with IEEE 802.11 a/b/g/n + BT 4.0 |
|
BT£¨Standard£© |
BT 4.0 |
|
WCDMA£¨3G£¬Standard£© |
WCDMA 3.75G£¨HSDPA+42.2Mbps,HSUPA+11.5Mbps£© |
|
GPS navigation£¨Standard£© |
GPS+Beidou+AGPS |
|
Fingerprint Module £¨Not waterproof, optional£© |
FPC1020 fingerprint chip |
|
Camera£¨optional£© |
Rear 13 million pixels with auto focus electronic flash Front 5 million pixel camera |
|
Headphone Jack |
¡Ó3.5mm standard headphone jack |
|
RFID Module Specifications |
|
|
Data Transmission |
USB Micro 5Pin |
|
RFID Module |
UHF(optional) ¡¢NFC£¨optional£© |
|
Scan Module |
Imported 2D scanning head (optional) |
|
Power Supply Battery |
3.7V£¬11000mAh Lithium Polymer Battery |
|
Accessories |
5V/2A 1 charger, 1 USB data communication line |
|
RFID Parameter |
|
|
NFC Module |
Working Frequency£º 13.56MHz |
|
Support Protocol |
ISO14443A¡¢ISO15693 |
|
Reading Distance |
0¡«7cm(related to tags) |
|
UHF Module |
Working Frequency£º902MHz¡«928MHz£¨default£© £¬customizable frequency range£º860MHz¡«960MHz |
|
Supportable Protocol |
EPC C1 G2(ISO18000-6C£© |
|
Reading Distance |
2m above(related to tags) |
|
Physical Parameter |
|
|
Total Weight |
820g |
|
Dimensions(mm) |
256£¨Length£©¡Á159£¨Width£©¡Á23£¨Height£©mm |
|
Environmental Parameters |
|
|
Operating Temperature |
-20¡æ¡«55¡æ |
|
Storage Temperature |
-40¡æ¡«80¡æ |
|
Storage Humidity |
5£¥¡«95£¥RH£¬non-condensing |
|
Protection Grade |
IP67 |
