Introduction：
1. Based on independent intellectual property rights development, design patents, UHF Bluetooth communication handsets；
2. Excellent UHF reading and writing performance, adapt to the global frequency；
3. Multiple indications of working status, multi-color LED indicator, buzzer, vibration motor to meet various working environments；
4. Flexible wireless Bluetooth communication, hand-held reader can be easily used online with smart terminals (smartphones, tablets, etc.)；
5. Software integration is fast and efficient, providing SDK development files based on Android and Apple iOS system platforms;
Features：
1. UHF reading distance 2～2.5 meters（test tag：Impinj E41b）；
2. Online use of Bluetooth communication with existing PDAs, smartphones, tablets, etc. reduces the cost of repeated purchases；
3. Support ISO-18000-6B, ISO-18000-6C (EPC G2) protocol tag reading and writing；
4. Easily confirm the reading tag while confirming and viewing on the PDA screen；
5. Low cost, more cost-saving than PDA integrated handheld reader；
Application：
6. Department Store Commercial Retail (Apparel, Footwear, Jewelry and etc.)
7. Assets management and inventory
8. Warehouse logistics management
Anti-counterfeiting traceability
|
Model No. |
VH-H75/VH-H75T |
|
UHF RFID Parameter |
|
|
RF module |
VANCH VM-5GA |
|
Frequency |
902～928MHz,865～868MHz |
|
Built-in Antenna |
2dbi circular polarization ceramic antenna |
|
Protocol |
EPCglobal UHF Class 1 Gen 2 / ISO 18000-6C |
|
Output power |
18～26dBm adjustable ±1dBm |
|
R/W distance(VH-75) |
Read distance 2～2.5m，write distance>20cm（test tag：Impinj E41b） |
|
R/W distance(VH-75T) |
Read distance >5m，write distance>20cm（test tag：Impinj E41b） |
|
Multi-tag reading speed |
＞50 tags/s（peak value） |
|
Support areas |
U.S., Canada, and other regions that comply with U.S. FCC Part 15 regulations Europe and other regions that comply with ETSI EN 302 308 China, India, Japan, South Korea, Malaysia, Taiwan |
|
Electrical Parameter |
|
|
CPU control chip |
ARM（STM32F103） |
|
Tag ID storage |
128MB(NandFlash) |
|
USB interface type |
Micro-B，USB2.0 |
|
Wireless communication |
Bluetooth 4.0 |
|
Communication rate |
9600～115200bps， |
|
Reliable firmware upgrade |
Scalable upgrade mechanism |
|
Application software interface |
Provide API development kits and application routines based on Android and Apple iOS system platforms |
|
Tag reading indicator |
Vibration motor、Buzzer、LED |
|
Standby time |
150 hours |
|
Battery |
Rechargeable lithium battery（3.7V,4000mAH） |
|
Environment Parameter |
|
|
Humidity |
5%RH ～95%RH(non-condensing) |
|
Protection level |
IEC IP64 |
|
Operating temperature |
-20ºC～ +60ºC |
|
Storage temperature |
-25ºC～+70ºC |
|
Earthquake resistant height |
1.2m/6.56ft |
|
Physical Parameter |
|
|
Size |
180(L)*65 (W)*65(H)mm |
|
Net Weight |
250g（Including battery） |
|
Shell Material |
ABS+PC |
|
Accessories |
|
|
Battery Charging/Data Cable Lanyard |
|
