2. Supports electronic tags in formats such as EMID and FDX-B (ISO1784/85);
3. Adopts 1.44" TFT display to clearly display the tag number and device status;
4. Built-in storage function, can store up to 1,000 tag information;
5. Can be uploaded to a computer via a USB data cable, and can also be uploaded to a device in real time via wireless 2.4G or Bluetooth.
|
Purchase code (product model) |
VH-L1877 |
|
Performance Parameters |
|
|
Working frequency |
134.2Khz/125Khz |
|
Tag format |
EMID、FDX-B(ISO11784/85) |
|
Read and write distance |
2~12mm glass tube tag>8cm 30mm animal ear tag>20cm (related to tag performance) |
|
Standard |
ISO11784/85 |
|
Read time |
＜100ms |
|
Wireless distance |
0-80m (open space) |
|
Bluetooth distance |
0-20m (open space) |
|
Signal Indication |
1.44 inch TFT LCD screen, buzzer |
|
Power supply |
3.7V (800mAh lithium battery) |
|
Storage capacity |
1000 messages |
|
Communication interface |
USB2.0, wireless 2.4G, Bluetooth (optional) |
|
Language |
English (customizable according to customer requirements) |
|
Operating temperature |
-10℃~50℃ |
|
Storage temperature |
-30℃~70℃ |
|
Humidity |
5%-95% non-condensing |
|
Product size |
182mm×77mm×17.5mm |
|
Net weight |
78g |
